A5-BA01
Auroraheat provide heating output via continuous heating poweroutput via stepless modulation, ensuring constant temperatures. Theheater operates quietly and consumes very little power and fuel.
The air heater can be used as a stand-alone heating solution or as anadd-on system to existing heating solutions. Therefore Auroraheatoffers heaters with different power outputs, ranging from 1.0 kW up to 2.0 kW. All Auroraheat can be either mounted outside, in thedouble-floor or inside the vehicle.
Advantages
* Optimum heat output at high altitudes thanks to integrated altitude sensor (Pro Evo range)
*Heating power from 1.0 kW to 2.0 kW
*Very compact heater for easy and fast installation
*Smooth blower and burner operation for low noise and fuel consumption
* Hot air is distributed through a ducting system into the motor home, ensuring a constant temperature
*Precise and stepless cabin temperature control
*Very fast heat-up phase
*Diesel-fueled, directly fed from the tank
The air heater can be used as a stand-alone heating solution or as anadd-on system to existing heating solutions. Therefore Auroraheatoffers heaters with different power outputs, ranging from 1.0 kW up to 2.0 kW. All Auroraheat can be either mounted outside, in thedouble-floor or inside the vehicle.
Advantages
* Optimum heat output at high altitudes thanks to integrated altitude sensor (Pro Evo range)
*Heating power from 1.0 kW to 2.0 kW
*Very compact heater for easy and fast installation
*Smooth blower and burner operation for low noise and fuel consumption
* Hot air is distributed through a ducting system into the motor home, ensuring a constant temperature
*Precise and stepless cabin temperature control
*Very fast heat-up phase
*Diesel-fueled, directly fed from the tank
Heating capacity：1.0 KW / 2.0 KW
Fuel consumption：0.1L/H / 0.2L/H
Nominal voltage：12V/24V
Nominal power consumption：includingoil pump 6W(part load)/20w(full load)
Fuels：diesel
Operating temperature：-40℃ to 80℃
Dimensions：30CM*11CM*11CM
Altitude above sea level：up to 4000M
Weight：5.5 KG
Version：Pro/Evo
Consult Now
Detail
| Heating capacity, part load /full load(kW) | 1.5/5.0 |
| Fuel consumption, part load /full load(l/ h) | 0.13/0.45 |
| Nominal voltage (V) | 12V / 24V |
| Nominal power consumption includingoil pump, part load/full load (W) | 6/20 |
| Fuels | diesel |
| Operating temperature range (°C) | -40 to +80 |
| Dimensions LxWxH(cm) | 38*14*14 |
| Weight (kg) | 6.5 |
| Permissible high altitudelevel above sea level(m) | up to 4000 |
| Version | Pro / Evo |
